M24 Orion
Performance
115 mph
95 mph
1500 ft/min
12000 ft
300 ft
0 - 50 ft
25 knots
4.5 - 6.5 gph
3 - 4.5 hours
325 miles
21 gallons
Max Speed:
Cruise:
Rate of Climb
Service Ceiling:
Takeoff Roll:
Landing Roll:
Max Crosswind:
Fuel Burn:
Endurance:
Range:
Fuel Capacity:
Specifications
Side by Side
28 ft
9 ft 1 in
14 ft 6 in
5 ft 10 in
Rotax 915iS/916iS
665 lbs
1320 lbs
40 lbs
Carbon Fiber
4130 Steel
Composite
DUC 4 Blade
Full Dual
Beringer
Configuration:
Rotor Diameter:
Height:
Length:
Width:
Engine:
Empty Weight:
Gross Weight:
Baggage:
Fuselage:
Frame:
Rotor:
Propeller:
Controls:
Wheels:
Xtreme M24
The Xtreme version of the M24 has been a game-changer pilots who enjoy the side by side experience but want a fully capable off-airport machine. The Fox Shock on the front nose wheel and the 21” smooth tundra tires on the main wheels absorb the movement of the terrain that would have been otherwise transferred to the chromoly steel frame, providing a much smoother handling of difficult terrain. The tradeoff is speed - you’ll lose 3-5 mph at cruise, but for those who long for the extra capability provided, it is well worth it.
